Corrugated 7 8 Feeder Cable 50 Ohms PE Coaxial 7/8'' Hard Line Cable yeRF Transmission

DZICHIBUDA

Mutengo (USD): Kumbira Kotesheni
Kuwanda (PCS): 1
Kutumira (USD): Kumbira Kotesheni
Zvose (USD): Kumbira Kotesheni
Kutumira Nzira: DHL, FedEx, UPS, EMS, NeGungwa, Nemhepo
Kubhadhara: TT (Bank Transfer), Western Union, Paypal, Payoneer

Chii chinonzi FMUSER 7 8 Feeder Cable?

Muindasitiri yezvishandiso zvekutepfenyura, 7 8 Feeder Cable ine mazita akawanda, akadai se:

7 8 coaxial tambo
7 nhema
7/8 '' feeder pipe
7 feeder
7/8 feed tube
7 8 coax feeder
etc.

Nekuti kutaridzika kweiyo coaxial mhinduro chubhu yakafanana neyeiyo coaxial feed mutsara uye kunyangwe tambo, pane kazhinji nzira mbiri dzinogona kusiyaniswa kubva kune imwe neimwe:

The shielding layer

Iyo shielding layer ye feeder ine shielding line. Mutsetse wekudzivirira tambo yekutumira yakaputirwa mumutsara wechiratidzo uchishandisa simbi mesh yakarukwa layer. Iyo shielding layer inoumbwa nechubhu yemhangura.

Sizes

Iyo yekudyisa uye yekudyisa zvakare zvakasiyana zvakanyanya muhukuru. Kune mutsara wekudyisa, ivo vanowanzova vakanyanya kunaka, uye yakajairika saizi yekudyisa ndeye:

RG-6 (6.15mm)
RG-11 (10.30mm)
RG-58 (4.95mm)
RG-59 (6.15mm)
RG-62 (6.15mm)
RG-12 (14.10mm)
RG-213 (10.33)

Iyo mhinduro chubhu yakakora, uye yakajairika mhinduro chubhu saizi ndeiyi:

1 / 2 ''
7 / 8 ''
1-5 / 8 ''
3-7 / 8 ''
etc.

Zvigadziri

Zvakakodzera kutaura kuti kune maviri ekutanga marudzi ehukuru (1/2 uye 7/8), pane maviri magadzirirwo: hollow uye akasimba conductor, uye ekupedzisira maviri ekupedzisira anowanzo asina chinhu madhizaini, kunyangwe asina hollow Mutengo wecoaxial mhinduro chubhu. inodhura zvakanyanya, kuita kwayo kuchave kwakasimba kupfuura iyo yakasimba mhinduro manejimendi, uye yakanyanya kuoma kugadzirisa.

FMUSER 7 8 coaxial tambo inogara iri mustock yenhepfenyuro 700px.jpg

Pamusoro pemusiyano muhukuru, kuita kuri nani pane vakajairwa vanodyisa, izvo zvinoenderana neyakasiyana dhizaini yeanodyisa, anosanganisira Solid Shields, foam dielectric, uye conductor yemhangura.

Kuti tisangane nezvinodiwa nevatengi vakasiyana, isu tinopa zvakare hollow 7 8 feeder tambo, dzinochinjika uye dzinobhenda kupfuura dzakasimba tambo dzekudyisa. Ndapota taura neboka redu rekutengesa kana iwe uchida mamwe mashoko!

Bata izvozvi kuti uwane zvimwe

7 8 Feeder Cable Alternatives

Dzvanya zvinongedzo pazasi kuti uongorore zvimwe nezve 7/8 '' feeder cable dzimwe nzira, mutengo wepamusoro & mhando!


1/2'' Coax	1-5/8 '' Coax
Shanyira zvimwe nezve passive accessories, coaxial tambo, uye zvinongedzo. Zvimwe >>

Ndekupi Kutenga Yakanakisa 7 8 Feeder Cable?

FMUSER ndiye mugadziri wekutanga we 7 8 feeder cable. Muzhinji FM/AM/TV nhepfenyuro, yedu 7 8 coaxial tambo inogona kuiswa nyore nyore mukubatana kweiyo transmitter antenna masisitimu

Fekitori yekugadzira yeFMUSER 7 8 feeder tambo 700px.jpg

Kunyanya kukosha, wese wekupedzisira-mushandisi weFMUSER 7 8 coax achavimbiswa ne:

Basa rakatanhamara
Ultra flexibility
Kurasikirwa kwakaderera kana kuderera kuderera
Yakaderera PIM (passive intermodulation)
UV kuramba
Easy-management, nyore-kuisa
Fire resistance


FMUSER 7-8 feeder tambo ine yakavimbika yekupisa conductivity, iyo inokonzerwa nekunaka kwayo yakaderera attenuation maitiro, ayo anopa hupenyu hwechigadzirwa, izvi zvinoderedza mutengo wenguva refu wekushandisa kwenhepfenyuro. Nekuda kwefekitori yedu yekugadzira, iyi 7 8 hardline coaxial tambo inogona kuiswa mune dzakasiyana siyana dzekushandisa, senge:

Indoor
Wireless Communication
TV & Radio
HF Defense
microwave
Sravana Sameeralu Serial XNUMXth Mobile Radio
Cable Solutions

Kumbira quote

Terms	Specs	Notes
chisimba
Inner conductor	9.4mm	Spiral wrinkle mhangura chubhu
Insulator	21.5mm	Foamed polyethylene
Outer conductor	25.0mm	Mhete wrinkle mhangura chubhu
jacket	27.5mm	Polyethylene / flame retardant polyolefin
Static minimum bending radius	80mm	Kukotama kumwechete
Dynamic shoma yekupeta radius	125mm	Dzokorora kukotama ka15
Tensile simba	2000N	N / A
Cable uremu	500 (550) kg/km	N / A
RF
Characteristic impedance	50±1Ω	N / A
Kuendeswa kwechikamu	0.88	Nominal value
Minimum insulation resistance	500MΩ km	DC500V 1 miniti
capacitance	76pF/m	Nominal value
Kushingirira voltage	DC6000V	1 miniti
Rated yepamusoro simba	90KW
Peak voltage	3100V
Typical voltage standing wave ratio	1.08	800M ~ 1000MHz
	1.08	1700M ~ 2000MHz
	1.08	2100M ~ 2400MHz
Avhareji Simba
maitikiro	Kuchengetedzwa	Average power
10	0.39	21.5
100	1.29	5.6
150	1.59	5.4
200	1.85	4.6
300	2.29	3.7
450	2.85	3
500	3.02	2.82
700	3.62	2.39
800	3.89	2.2
900	4.15	2.07
1000	4.4	1.95
1500	5.52	1.55
1700	5.92	1.45
1800	6.12	1.4
1900	6.31	1.35
2000	6.49	1.31
2100	6.68	1.28
2200	6.86	1.25
2400	7.22	1.2
2500	7.38	1.17
2700	7.72	1.1
3000	8.2	1.04
3400	8.84	0.98
4000	9.74	0.89
5000	11.13	0.78
